Pressure Sensors Series PS…
Pressure Sensors Series PS
11 Adjustable parameters and their meaning
11.1 Standard parameters
Parameter Explanation Options Function
Loc Disabling the program-
ming mode
Programming mode fully disabled/
locked
uLoc Enabling the program-
ming mode
Programming mode enabled/unlo-
cked (default/ex factory)
Uni Display unit bar
psi
kPa
MPa
Ud1-Ud10
bar (LED green)
psi (LED green)
kPa (LED green)
MPa (LED green)
see page 9 (LED green)
ou1 Function of output 1 Hno1 Hysteresis function
(NO = normally open)
Hnc1 Hysteresis function
(NC = normally closed)
Fno1 Window function
(NO = normally open)
Fnc1 Window function
(NC = normally closed)
SP1 Switchpoint 1 in
hysteresis mode
upper limit value, at which output
1 changes the switching state with
increasing pressure
rP1 Reset point 1 in hysteresis
mode
lower limit value, at which output
1 changes the switching state with
decreasing pressure
FH1 Upper switchpoint by
window function
Upper switchpoint, at which out-
put 2 changes the switching state
FL1 Lower switchpoint Lower switchpoint, at by window
function which output 1 changes
the switching state
