turck PS Series Instruction Manual

Hans Turck GmbH & Co. KG • Tel. +49 (0) 208/4952-0 • Fax +49 (0) 208/4952-264
14
Pressure Sensors Series PS…
Standard parameters – Continuation
Parameter Explanation Options Function
ou2 Function of output 2
(Switching output)
Only type:
PS…-2UPN8X,
PS…-LI2UPN8X
Hno2 Hysteresis function
(N/O = normally open)
Hnc2 Hysteresis function
(N/C = normally closed)
Fno2 Window function
(N/O = normally open)
Fnc2 Window function
(N/C = normally closed)
Current output
Only type:
PS…-LI…
4-20
0-20
rising straight line
20-4
20-0
falling straight line
Voltage output
Only type:
PS…-LU…
0-10
0-5
1-6
rising straight line
10-0
5-0
6-1
falling straight line
SP2 Switchpoint 2
Only type:
PS…-2UPN8X,
PS…-LI2UPN8X
Upper limit value, at which output
2 changes the switching state with
increasing pressure
rP2 Reset point 2
Only type:
PS…-2UPN8X,
PS…-LI2UPN8X
Lower limit value, at which output
2 changes the switching state with
decreasing pressure
FH2 Upper switchpoint by
window function
Upper switchpoint, at which out-
put 2 changes the switching state
FL2 Lower switchpoint by
window function
Only type:
PS…-2UPN8X,
PS…-LI2UPN8X
Lower switchpoint, at which output
2 changes the switching state
ASP Initial point of the analog
signal
Only type: PS…-LUUPN8X,
PS…-LI2UPN8X
pressure value indicating the initial
point of the analog signal
AEP End point of the analog
signal
Only type:
PS…-LUUPN8X,
PS…-LI2UPN8X
pressure value indicating the end
point of the analog signal
EF Extra menu for additional
settings
To access the settings in the
submenu press the Set-button,
see 11.2
