Tuthill PD Plus - Specifi Cations

Manual 2007 Rev B p/n 2007
8
04
Description
SPECIFICATIONS
MODEL
APPROXIMATE OIL
CAPACITY
PORT SIZE
MAXIMUM
RPM
APPROXIMATE WEIGHT
VERTICAL
FLOW
HORIZONTAL
FLOW
VERTICAL
FLOW
HORIZONTAL
FLOW
7010 8.0 qt (7.5 L) 5.0 qt (4.75 L) 6 in. (150 mm) 3,000 – 1,120 lb (510 kg)
7013 8.0 qt (7.5 L) 5.0 qt (4.75 L) 8 in. (200 mm) 3,000 1,255 lb (570 kg) –
7017 8.0 qt (7.5 L) 5.0 qt (4.75 L) 10 in. (250 mm) 3,000 – 1,390 lb (635 kg)
7021 8.0 qt (7.5 L) 5.0 qt (4.75 L) 12 in. (300 mm) 3,000 1,530 lb (695 kg) 1,530 lb (695 kg)
7026 8.0 qt (7.5 L) 5.0 qt (4.75 L) 12 in. (300 mm) 3,000 1,695 lb (770 kg) 1,695 lb (770 kg)
Table 4-1 – Specifi cations (Sump Oil Lubrication)
MODEL
APPROXIMATE OIL
CAPACITY
PORT SIZE
MAXIMUM
RPM
APPROXIMATE WEIGHT
VERTICAL
FLOW
HORIZONTAL
FLOW
VERTICAL
FLOW
HORIZONTAL
FLOW
7010 15qt (14.2 L) 12 qt (11.4 L) 6 in. (150 mm) 3,000 – 1,120 lb (510 kg)
7013 15qt (14.2 L) 12 qt (11.4 L) 8 in. (200 mm) 3,000 1,255 lb (570 kg) –
7017 15qt (14.2 L) 12 qt (11.4 L) 10 in. (250 mm) 3,000 – 1,390 lb (635 kg)
7021 15qt (14.2 L) 12 qt (11.4 L) 12 in. (300 mm) 3,000 1,530 lb (695 kg) 1,530 lb (695 kg)
7026 15qt (14.2 L) 12 qt (11.4 L) 12 in. (300 mm) 3,000 1,695 lb (770 kg) 1,695 lb (770 kg)
Table 4-2 – Specifi cations (Integral Lubrication)
