Tuthill PD Plus - Assembly Clearances

Manual 2007 Rev B p/n 2007
39
MODEL GEAR END FREE END INTERLOBE TIP-DOWEL TIP-PORT
7010
0.006 – 0.009 in.
(0.15 – 0.23 mm)
0.013 – 0.019 in.
(0.33 – 0.48 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
7013
0.006 – 0.009 in.
(0.15 – 0.23 mm)
0.016 – 0.022 in.
(0.41 – 0.56 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
7017
0.006 – 0.009 in.
(0.15 – 0.23 mm)
0.021 – 0.027 in.
(0.53 – 0.69 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
7021
0.006 – 0.009 in.
(0.15 – 0.23 mm)
0.026 – 0.032 in.
(0.68 – 0.81 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
7026
0.006 – 0.009 in.
(0.15 – 0.23 mm)
0.031 – 0.037 in.
(0.79 – 0.94 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
ASSEMBLY CLEARANCES
