Tuthill PD Plus - Special Tool Drawings

Manual 2007 Rev B p/n 2007
43
2.75
Ø
69.85
3.00 Ø
76.2
45°
3.40 Ø
86.36
3.740 Ø
94.996
4.720 Ø
119.888
4.240 Ø
107.696
2.25
57.15
0.700
17.78
1.940
49.276
3.860
98.044
5.75
146.05
Figure 13-1 – Lab Seal Pressing Tool
5.75 Ø
146.05
1.30
33.02
3.00
76.2
Ø 5.121
± 0.001
Ø 130.073
± 0.0254
Ø 4.7245
± 0.005
Ø 120.0023
± 0.127
Figure 13-2 – Seal Installation Tool
2.75
Ø
69.85
1.25
31.75
2.25
57.15
4.62
117.35
4.62
± 0.0025
70.9041
± 0.0635
0.9025
± 0.0025
22.9235
± 0.0635
2.00 Ø
50.8
3.75 Ø
95.25
Ø 4.241
± 0.001
Ø 107.721
± 0.0254
Ø 4.719
± 0.001
Ø 1
19.863
± 0.0254
SHARP CORNER
0.25 R
Figure 13-3 – Mechanical and Lip Seal Tool
2.77 Ø
70.358
4.700 Ø
119.38
4.22 Ø
107.19
2.175 Ø
55.245
2.93 Ø
74.42
2.30
58.42
0.625
15.875
0.100
2.54
Figure 13-4 – Bearing Pressing Tool
SPECIAL TOOL DRAWINGS
13
