Parts List
PARTS LIST
Parts List for Model 7000 Series – Lip/Lap Seals
ITEM
NO.
PART DESCRIPTION QTY
1 Rotor 2
3 Housing 1
4 End Plate 2
6 Drive End Cover 1
7 Free End Cover 1
8 Timing Gear Set 1
9 Bearing, Drive End 2
10 Bearing, Free End 2
12 Lip Seal, Viton 4
13 Lip Seal, Viton 1
14 Retainer 2
15 Retainer 2
20 Oil Slinger 1
22 Dowel Pin 8
23 Drive Shaft Key 1
24 Gear Key 2
25 Rotor Shaft Washer 4
26 Cap Screw 36
29 Bolt 4
30 Cap Screw 16
31 Magnetic Pipe Plug 2
37 Breather 2
42 Nameplate 1
45 Drive Shaft 1
50 Bearing 1
51 Lab Seal 4
59 Rotor Locking Tab 4
66 Cap Screw 4
68 Dowel Pin 4
70 Sight Gauge Window 2
80 Lock Washer 4
85 Pipe Plug 14
ITEM
NO.
PART DESCRIPTION QTY
91 Nose Piece Lip Seal 1
92 O-Ring, Viton 1
93 Cap Screw 4
100 Straight Thread Adapter 2
109 Plug 12 / 0
195 Lifting Lug 2
196 Cap Screw 2
199 O-Ring, Viton 2
304 Mounting Foot 2
307 Cap Screw 4
339 Plug 4
395 Oil Slinger 2
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
