Manual 2007 Rev B p/n 2007
50
Parts List
Parts List for Model 7000 Series – Internal Lube Single Mechanical Seals
ITEM
NO.
PART DESCRIPTION QTY
1 Rotor 2
3 Housing 1
4 End Plate 2
6 Drive End Cover 1
7 Free End Cover 1
8 Timing Gear Set 1
9 Bearing, Drive End 2
10 Bearing, Free End 1
10 Bearing 1
13 Lip Seal, Viton 1
14 Retainer 3
15 Retainer 1
20 Oil Slinger 1
22 Dowel Pin 8
23 Drive Shaft Key 1
24 Gear Key 2
25 Rotor Shaft Washer 3
26 Cap Screw 36
29 Bolt 3
30 Cap Screw 16
31 Magnetic Pipe Plug 1
37 Breather 2
42 Nameplate 1
45 Drive Shaft 1
50 Bearing 1
51 Lab Seal 4
54 Mechanical Seal 4
57 Rotor Spacer 1
59 Rotor Locking Tab 3
66 Cap Screw 4
67 Bearing Spacer 1
68 Dowel Pin 3
69 Cap Screw 4
74 Sealing Ring 4
ITEM
NO.
PART DESCRIPTION QTY
75 O-Ring, Viton 4
80 Lock Washer 4
91 Nose Piece Lip Seal
Adapter
1
92 O-Ring, Viton 1
93 Cap Screw 4
100 Adapter 2
101 St Elbow 1
102 Pipe Tube 1
106 Pipe Coupling 1
109 Pipe Plug 14
110 Cap Screw 3
121 Pipe Plug 10
122 Set Screw 2
124 Oil Filter, Spin On 1
125 Pump Mounting Bracket 1
135 Union, Tee, Tube 4
136 Lock Washer 4
144 Oil Pump 1
155 Tube Elbow 2
163 Tube Elbow 2
172 Reducing Bushing 1
174 Pipe Plug 1
187 Tube 1
188 Tube Elbow, Union 2
195 Lifting Lug 2
196 Cap Screw 2
212 Cap Screw 2
226 Flat Washer 2
235 Male Tube Adapter 5
262 Gauge, 30 Hg - 30 PIS,
Liquid Filled
1
265 Bypass Relief Valve 1
270 Oil Filter Adapter 1
271 Pipe Plug 2
