Tuthill T855 - Page 20

Operator’s Manual 2023 Rev G p/n 2023
16
04
Installation
T1050 / T1055 PRESSURE CURVE
2
5
8
10
12
15
18
PSIG
PSIG
18
15
12
10
8
5
2
10001500 2000
RPM
2500 3000
Airflow at Inlet (CFM)
0
150
300
450
600
750
900
1050
1200
1350
0
15
30
45
60
75
90
105
120
BH
P
AIRFLOW BASED UPON INLET
CONDITIONS OF:
14.7 PSIA & 70° F
# PSIG DISCHARGE PRESSURE
Figure 4-8 – T1050 / T1055 Pressure Curve (US)
