[ENTER/F3] Button
- Used to conrm a chosen value (or mode).
- If the main/sub menu is not activated, the feature selected in “SYSTEM- >ENTER/F3” setting will
be activated.
- Use UP/DOWN keys to select and proceed through various functions.
- See section “Other Functions [2]SCAN button” for more information.
[OPERATE] Lamp
- Indicates condition and power status of unit.
- Light turns o when the power is disconnected.
- Standby mode is indicated by a red LED light.
- Normal (active) mode is indicated by a Green LED light.
- Restores to previous state when monitor power turns o and comes back on.
[POWER] Button
- Used to turn power on and o.
[TALLY] Lamp
- Tally lamp that can be toggled in green or red using the REMOTE(RJ-45) port.
[APERTURE] knob (LVM-173W-3G)
- Used to adjust the picture sharpness.
- Control value range: 0 ~ 25
- Unavailable in DVI ANALOG Mode.
[BRIGHT] knob (LVM-173W-3G)
- Used to adjust the degree of brightness.
- Control value range: -100 ~ 100
[CHROMA] knob (LVM-173W-3G)
- Used to adjust the saturation of the image.
- Control value range: -50 ~ 50
- Unavailable in RGB, DVI ANALOG, DVI DIGITAL and HDMI modes.
[CONTRAST] knob (LVM-173W-3G)
- Used to adjust the contrast.
- Control value range: -100 ~ 100
[VOLUME] knob (LVM-173W-3G)
- Used to adjust the volume for internal speaker and external output.
- Control value range : 0 ~ 30
Controls, Indicators and Connections
