TVLogic LVM-245W User Manual

Multi Format LCD Monitor
27
Menu Contents
<Dynamic UMD Protocol (TSL V3.1)>
*
Transmission (18 Byte) (PC or Device -> Monitor)
*
[HEADER] : Display address (0~126) + 80 hex.
*
[CONTROL BYTE]
bit 0 : Tally 1 (1=on, 0=o)
bit 1 : Tally 2 (1=on, 0=o)
bit 2 : Tally 3 (1=on, 0=o)
bit 3 : Tally 4 (1=on, 0=o)
bit 4 : bright data (Not used)
bit 5 : bright data (Not used)
bit 6 : reserved (Not used)
bit 7 : cleared to 0 (Not used)
*
[DISPLAY DATA] : 16 displayable ASCII characters.
HEADER
(1 BYTE)
CONTROL BYTE
(1 BYTE)
DISPLAY DATA
(16 BYTE)

Tally1
&+$11(/
Tally2 Tally3
&+$11(/
Tally4
