Multi Format LCD Monitor
26
Multi Format LCD Monitor
26
MONITOR ID
- Sets the ID of each monitor for the TV Logic control protocol or DYNAMIC UMD using RS-422/485
communication.
- Available values are between 0,2,4 ~ 98.
- Right screen in PBP mode is automatically set to +1 of the monitor ID.
UMD DISPLAY
- Sets input source ID mode.
- Available modes are OFF, UMD, ANC, D-UMD(S-8C), D-UMD(S-16C) and D-UMD(D-8C).
-
If UMD menu is selected, characters or tally data in the black bar displays on the bottom of the screen.
The vertical aspect ratio of the image changes on the screen as the bar on the bottom of screen
appears.
- In the USER ASPECT mode, the UMD bar displays semi-transparently and the screen keeps its USER
ASPECT ratio.
*
UMD : Displays user customized 8 characters on screen.
*
ANC : Displays characters embedded in SDI signal.
*
D-UMD(S-8C) : Displays incoming data of 8 characters and tally signal from TSL protocol (V3.1).
*
D-UMD(S-16C) : Displays incoming data of 16 characters and tally signal from TSL protocol (V3.1).
*
D-UMD(D-8C) : Displays incoming data of two pairs of 8 character strings and tally signals from
TSL protocol (V3.1).
- In PBP mode, even if D-UMD(S16C), D-UMD(D-8C) and D-UMD(S-8C) are selected, only D-UMD
(S-8C) activates.
- In PBP mode, each D-UMD(S-8C) for left screen and right screen are activated and adjustment for
each setting is available.
UMD CHARACTER
- Customizes the characters for Under Monitor Display.
- Alphabets, numbers and special symbols are available.
- Maximum of 8 characters are available.
D-UMD TALLY TYPE
- Tally type conguration setting in D-UMD(D-8C), UMD DISPLAY.
- Conguration values are DEFAULT and USER COLOR.
*
DEFAULT : Existing TV Logic operating system (VRT)
*
USER COLOR : User conguration settings on each TALLY color type.
- TALLY1 COLOR ~ TALLY4 COLOR are activated when USER COLOR is selected.
TALLY1 COLOR ~ TALLY4 COLOR
- This item sets the color of each TALLY1, TALLY2, TALLY3 and TALLY4 .
- Available color settings are Red, Green and Yellow.
