Multi Format LCD Monitor
29
Menu Contents
The following appearance of UMD DISPLAY is set as D-UMD(D-8C), D-UMD TALLY TYPE
and TALLY1 ~ TALLY4 COLOR.
D-UMD TALLY TYPE USER COLOR
TALLY1 COLOR RED
TALLY2 COLOR GREEN
TALLY3 COLOR RED
TALLY4 COLOR YELLOW
*
D-UMD TALLY TPYE – USER COLOR
- Color selections between TALLY1 ~ TALLY4.
PASSWORD
- Used to download the program via Ethernet. The password set for the monitor must match with
the password for the download program.
IP ADDRESS
- Sets the IP address.
SUBNET MASK
- Sets the subnet mask.
GATEWAY
- Sets the gateway.
PORT NO
- Sets the port number. Default port number is 10262.
REMOTE CONTROL
- Select the monitor control system by using ETHERNET or RS-422.
- Dynamic UMD is not activated, when the RS-422 is selected.
&+$11(/ &+$11(/
To Next Page
