Multi Format LCD Monitor
38
Multi Format LCD Monitor
38
Menu Contents
OSD POSITION
- Controls the OSD position.
-
Available positions are Center, Top-Left(L-T), Bottom-Left(L-B), Top-Right(T-R) and Bottom-Right(R-B).
KEY LED
- Controls key LED On/O.
-
If the button with LED is pressed with the KEY LED O, LED comes on but goes o after 5 seconds later.
F1/DOWN MAPPING
- User can select the function for F1/DOWN button.
- Selectable functions : BRIGHT, CONTRAST, VOLUME, FREEZE, WAVEFORM, TIMECODE, CC SEL,
ALM SEL, OUTPUT MODE, FAST MODE, DITHERING, FILTER, FORCE psf and UMD.
F2/UP MAPPING
- User can select the function for F2/UP button.
- Selectable functions : BRIGHT, CONTRAST, VOLUME, FREEZE, WAVEFORM, TIMECODE, CC SEL,
ALM SEL, OUTPUT MODE, FAST MODE, DITHERING, FILTER, FORCE psf and UMD.
F3/ENTER MAPPING
- User can select the function for F3/ENTER button.
- Selectable functions : BRIGHT, CONTRAST, VOLUME, FREEZE, WAVEFORM, TIMECODE, CC SEL,
ALM SEL, OUTPUT MODE, FAST MODE, DITHERING, FILTER, FORCE psf and UMD.
KEY LOCK
- This item locks all buttons except power, input select, and menu buttons.
*
LVM-173W-3G locks the knobs(APERTURE, BRIGHT, CHROMA, CONTRAST, VOLUME) also.
INTERNAL PATTERN
- This item generates internal white pattern. The white level select between 0% and 100% (Per 5%
increase or decrease).
SET DEFAULT
- User can use the SET DEFAULTS.
- Feature to initialize the values to 0 of BRIGHT, CONTRAST, PHASE, CHROMA, APERTURE and NOISE
REDUCTION of the monitor.
INFOMATION
- Board version and current status information.
