TVLogic LVM-245W User Manual

Multi Format LCD Monitor
34
Multi Format LCD Monitor
34
Menu Contents
 RANGE ERROR
- Used to display the values of Y MAX, Y MIN, C MAX, C MIN, Y PICTURE BLINK, and C PICTURE BLINK
on the screen.
- Selected values in Y MAX, Y MIN, C MAX, C MIN are indicated in WAVEFORM/VECTOR or Y/Cb/Cr.
- If Y PICTURE BLINK or C PICTURE BLINK is enabled, the section of image that exceeds the selected
values of Y MAX, Y MIN, C MAX and C MIN blinks.
 Y MAX
- This item sets the maximum luminance level.
- Available values are between 0 ~ 127. Exceeded selection displays on the top portion of the
waveform or display.
 Y MIN
- This item sets the minimum luminance level.
- Available values are between 0 ~ 127. Exceeded selection displays on the top portion of the
waveform or display.
 C MAX
- This item sets the maximum chroma level.
- Available values are between 0 ~ 127. Exceeded selection displays on the top portion of the
waveform or display.
 C MIN
- This item sets the minimum chroma level.
- Available values are between 0 ~ 127. Exceeded selection displays on the top portion of the
waveform or display.
 Y PICTURE BLINK
- This item sets selections of image that exceeds Y MAX and Y MIN to blink.
 C PICTURE BLINK
- This item sets selections of image that exceeds C MAX and C MIN to blink.
