TVLogic LVM-245W User Manual

Multi Format LCD Monitor
47
Product Specications
LVM-243W-3G
LCD
Size 24”
Resolution 1920 X 1200 (16:10)
Pixel Pitch 0.270(H) X 0.270(W) mm
Color Depth 16.7M (True 8bit)
Viewing Angle H : 176 degrees / V : 176 degrees
Luminance of white
400 cd/ m
2
ٻ(Center)
Contrast 1000 : 1
Display Area 518.4(H) X 324.0(V) mm
Input
1 X DVI-I DVI-I(RGB) IN
3 X BNC Analog Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC Analog Output
2 X BNC SDI A/B Channel (Loop Through Out)
Input Signal
Analog Composite / S-Video / Component / RGB
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA / IBM Modes
HDMI 480i / 480p / 720p / 1080i & VESA / IBM Modes
Analog Input Spec
Composite 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G with Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) 1080i(60/59.94/50)
SMPTE-372M
(Dual Link Option)
Dual HD-SDI YPbPr (4:2:2) 1080p (50 / 59.94 / 60)
Dual HD-SDI YPbPr/RGB (4:4:4)
1080p (50 / 59.94 / 60)
1080p/psf (30/29.97/25/24/23.98)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
2K Format 2048 X 1080 (23.98p/psf, 24p/psf)
Audio In Analog Stereo (Phone Jack), Embedded Audio
Audio Out Analog Stereo (Phone Jack), Internal speaker (stereo)
Power DC 12V/24V/AC100~240V (1.8A/50~60Hz)
Power Consumption (Approx.) 73 Watts(Typ.)
Operating Temperature
0୅Gto 35୅G(32
එ
Gto 95
එ
P
Storage Temperature
-20୅Gto 60୅G(-4
එ
Gto 140
එ
P
Main Body Dimensions (mm/inch) 552 X 389 X 95 (21.73 X 15.31 X 3.74)
Main Body Dimensions (with stand) 586 X 417 X 150 (23.07 X 16.41 X 5.90)
Box Dimensions (mm/inch) 673 X 535 X 280 (26.50 X 21.06 X 11.02)
Weight 11Kg / 24.2 lbs
Accessory AC Power cord
Option Carrying Case, 19” Rack Mountable Kit, Dual-Link, ND Filter
*
Above specications may be changed without notice.
