Product Specications
LVM-553W-3G
LCD
Size 55”
Resolution 1920 X 1080 (16:9)
Pixel Pitch 0.21 (H) X 0.63 (W) mm
Color Depth 16.7M (True 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white
700 cd/ m
2
ٻ(Typ.)
Contrast Ratio 4000 : 1
Display Area 1209.6 (H) X 680.4 (V) mm
Input Connector
1 X DVI-I DVI-I(RGB) IN
3 X BNC Analog Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC Analog Output
2 X BNC SDI A/B Channel (Loop Through Out)
Input Signal
Analog Composite / S-Video / Component / RGB
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA / IBM Modes
HDMI 480i / 480p / 720p / 1080i & VESA / IBM Modes
Analog Input Spec
Composite 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G with Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) 1080i(60/59.94/50)
SMPTE-372M
(Dual Link Option)
Dual HD-SDI YPbPr (4:2:2) 1080p (50 / 59.94 / 60)
Dual HD-SDI YPbPr/RGB (4:4:4)
1080p (50 / 59.94 / 60)
1080p/psf (30/29.97/25/24/23.98)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
2K Format 2048 X 1080 (23.98p/psf, 24p/psf)
Audio In Analog Stereo (Phone jack)
Audio Out Analog Stereo (Phone jack)
Power AC 100~240V (50~60Hz)
Power Consumption (Approx.) 516 Watts(Max)
Operating Temperature
0୅Gto 40୅G(32
එ
Gto 104
එ
P
Storage Temperature
-20୅Gto 60୅G(-4
එ
Gto 140
එ
P
Main Body Dimensions (mm/inch) 1266 X 800.2 X 255 (49.84 X 29.4 X 4.8)
Main Body Dimensions (with stand) 1266 X 747 X 121.3 (49.84 X 31.5 X 10.4)
Box Dimensions (mm/inch) 1420 X 920 X 385 (55.9 X 36.2 X 15.2)
Weight 48Kg / 105.8 lbs
Accessory AC Power cord
Option Carrying Case, Wall Mount
*
Above specications may be changed without notice.
