CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 30
Ringer Chassis
Ringer Chassis each occupy a single Power Slot in the CPS6000 Shelf.
Ringer Chassis Comcode
QS820M Ringer Chassis 108991262
Ringer Output Cable
Ringer Cables one per Ringer Output (Ringer Chassis).
Item Comcode
Ringer Output Cable H569-470 G kit – 15’ cable
with connector for CPS6000/CPS2000 shelf on
one end and unterminated leads on the other
end.
847922101
Commercial - Molex:
Plug 39-01-4031
Socket (3 per plug):
Terminal Type 5556
16 AWG 39-00-0079
18 AWG 39-00-0059
Tool 11-01-0197
Commercial
Ringers
Up to two Ringers plug into a Ringer Chassis.
One Ringer per Ringer Chassis is non-redundant (simplex).
Two Ringers per Ringer Chassis is 1 + 1 redundant (duplex).
Ringer Comcode
QS820A Ringer 108990082
AC Power Cables
An ac power cable must be ordered. A standard ac cable set will not fit in the CPS6000 shelf.
Verify that the sum of the input currents for all the rectifiers served by an ac circuit breaker
does not exceed 80% of the breaker’s rating.
