CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 31
Table 3-A: Shelf AC Input Current Table, Minimum Size CB or Fuse
QS860A – 500W rectifier (prelim) 120 Va 240 Vac
1 23-in. shelf with 5 power slots, dual feed 20A feed 1, 15A feed 2 15A feed 1, 15A feed 2
2 23-in. shelf with 4 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
3 23-in. shelf with 3 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
4 19-in. shelf with 4 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
5 19-in. shelf with 3 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
6 19-in. shelf with 2 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
7 19-in. shelf with 4 power slots, single feed 25A 15A
8 19-in. shelf with 3 power slots, single feed 20A 15A
9 19-in. shelf with 2 power slots, single feed 15A 15A
10 23-in. shelf with 5 power slots, single feed NA 20A
11 23-in. shelf with 4 power slots, single feed 25A 15A
12 23-in. shelf with 3 power slots, single feed 20A 15A
QS861A – 15A rectifier 120 Va 240 Vac
1 23-in. shelf with 5 power slots, dual feed 30A feed 1, 20A feed 2 20A feed 1, 15A feed 2
2 23-in. shelf with 4 power slots, dual feed 20A feed 1, 20A feed 2 15A feed 1, 15A feed 2
3 23-in. shelf with 3 power slots, dual feed 20A feed 1, 15A feed 2 15A feed 1, 15A feed 2
4 19-in. shelf with 4 power slots, dual feed 20A feed 1, 20A feed 2 15A feed 1, 15A feed 2
5 19-in. shelf with 3 power slots, dual feed 20A feed 1, 15A feed 2 15A feed 1, 15A feed 2
6 19-in. shelf with 2 power slots, dual feed 15A feed 1, 15A feed 2 15A feed 1, 15A feed 2
7 19-in. shelf with 4 power slots, single feed NA 25A
8 19-in. shelf with 3 power slots, single feed 30A 20A
9 19-in. shelf with 2 power slots, single feed 20A 15A
10 23-in. shelf with 5 power slots, single feed NA 30A
11 23-in. shelf with 4 power slots, single feed NA 25A
12 23-in. shelf with 3 power slots, single feed 30A 20A
QS852A – 20A rectifier 240 Vac
1 23-in. shelf with 5 power slots, dual feed 25A feed 1, 15A feed 2
2 23-in. shelf with 4 power slots, dual feed 15A feed 1, 15A feed 2
3 23-in. shelf with 3 power slots, dual feed 15A feed 1, 15A feed 2
4 19-in. shelf with 4 power slots, dual feed 15A feed 1, 15A feed 2
5 19-in. shelf with 3 power slots, dual feed 15A feed 1, 15A feed 2
6 19-in. shelf with 2 power slots, dual feed 15A feed 1, 15A feed 2
7 19-in. shelf with 4 power slots, single feed 30A
8 19-in. shelf with 3 power slots, single feed 25A
9 19-in. shelf with 2 power slots, single feed 15A
10 23-in. shelf with 5 power slots, single feed NA
11 23-in. shelf with 4 power slots, single feed 30A
12 23-in. shelf with 3 power slots, single feed 25A
