Guidelines and MANUFACTURER‘s declaration – ELECTROMAGNETIC
IMMUNITY
The OMEGO® Basic system is designed for operation in an ELECTROMAGNETIC ENVIRONMENT as indicated
below. The customer or user of the OMEGO® Basic system must ensure that it is used in such an
environment.
ELECTROMAGNETIC
ENVIRONMENT - Guidance
Electrostatic Discharge
(ESD)
IEC 61000-4-2
± 8 kV contact
± 15 kV air
± 8 kV contact
± 15 kV air
Floors should be wood,
concrete, or ceramic tile. If
floors are covered with
synthetic material, relative
humidity should be at least
30%.
Electrical Fast
Transient/Burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for
input/output lines
± 2 kV for power supply
lines
Not applicable
Mains power quality should
be that of a typical
commercial or hospital
environment.
± 1 kV differential
mode
± 2 kV common mode
± 1 kV differential
mode
± 2 kV common mode
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips, short
interruptions,
and voltage variations
on power
supply input lines
IEC 61000-4-11
< 5 % U
T
(> 95 % dip in U
T
) for
0.5 cycles
40 % U
T
(60 % dip in U
T
) for 1
cycles
70 % U
T
(30 % dip in U
T
) for
25 cycles
< 5 % U
T
(> 95 % dip in U
T
) for
5 sec.
< 5 % U
T
(> 95 % dip in U
T
) for
0.5 cycles
40 % U
T
(60 % dip in U
T
) for 1
cycles
70 % U
T
(30 % dip in U
T
) for 25
cycles
< 5 % U
T
(> 95 % dip in U
T
) for 5
sec.
Mains power quality should
be that of a typical
commercial or hospital
environment. If the
Users of the OMEGO® Basic
System Continued
FUNCTION also requests the
occurrence of power
interruptions, it is
recommended that
OMEGO® Basic System
consists of an
uninterruptible
Power supply or a battery to
feed.
Power Frequency
(50/60 Hz) Magnetic
Field
IEC 61000-4-8
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE: U
T
is the AC mains voltage before application of the test level.
