12
INSTALLING ACCESSORIES
SPOOL HOLDER
The first step of setting up your Ultimaker 2 Extended is attaching the spool holder at the back side of the 3D printer. In
the end, filament will be placed on the spool holder in order to properly guide it into the material feeder. Make sure to
install the spool holder as described below.
1. Take the spool holder and insert the top part in the corresponding hole at the back of the Ultimaker 2 Extended.
2. Push the spool holder down until it snaps into place.
GLASS PLATE
The glass plate is the print surface for prints on your Ultimaker 2 Extended. We are going to install it the following way.
1. Open up the two build plate clamps at the front side of the build plate by using a hex key.
2. Gently slide the glass plate over the build plate so that it snaps into the build plate clamps at the back side of the
build plate.
3. Close the two build plate clamps at the front to secure the glass plate.
CAUTION: The build plate clamps can be sharp, therefore it is advised to use one of the hex keys for opening the
build plate clamps.
