Step 2: Mounting the limit switches Assembling the frame 13
image 4: parts needed for this step
The orientation of the limit switches are engraved on the panels, except for the
FRONT panel.
The machine has 3 limit switches:
1 with BLUE wires
1with RED wires
1 with LONG BLACK wires
A
C
B
D
E
F
G H
I
