Ultimaker S3 User Manual

1
1
5 10
10
11
11
12
12
13
135
6
6
2
2
3
3
4 7 8 9
4
7 8 9
Ultimaker S3 and Ultimaker S5 user manual 8
2.1 Main components
Ultimaker S3
1. Glass door(s)
2. Print head
3. Build plate
4. Build plate clamps
5. Touchscreen
6. USB port
7. Feeder 2
8. Bowden tubes
9. Feeder 1
10. Power socket and switch
11. Ethernet port
12. Double spoolholder
with NFC cable
13. NFC socket
Ultimaker S5

Ultimaker S3 Specifications

General

Build Volume	230 x 190 x 200 mm
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Number of Print Heads	2
Print Speed	Up to 24 mm³/s
Heated Bed	Yes
Dual Extrusion	Yes
Operating Temperature	15 - 32 °C
Nozzle Diameter	0.4 mm
Connectivity	Wi-Fi, USB, Ethernet
Supported Materials	PLA, ABS, Nylon, CPE, PC, TPU, PP, PVA, Breakaway
Touchscreen	Yes
Feeder Type	Dual-geared feeder
Build Plate	Glass
Bed Leveling	Automatic
Power Requirements	100-240 V, 50-60 Hz
Layer Resolution	20 - 200 microns (0.0007 - 0.008 inches)
