10
Measuring probes connector
The device is fitted with a connector to accommodate a pair of probes which are linked by a Y-cable.
Figure 7- Probe connector and connection «Y» cable
1
2
Tags on the wires stand for:
1
Connector to be plugged on the UPSTREAM sensor
2
Connector to be plugged on the DOWNSTREAM sensor
