Ultraflux Minisonic II Portable User Manual

38
Logger / Data upload and exploitation
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Logger
Settings
File management
Logger
Settings
File management
Export to USB
Export selection
Select all
Example 1
Export to USB
Export selection
Select all
Example 1
Export to USB
Export selection
Select all
Example 1
Export to USB
Export selection
Select all
Example 1
File management
Export to USB
Delete files
Question
Ok
Cancel
Question
Are you sure you want
to export data to
a USB key ?
q
In Export to USB submenu, choose and tag the file(s) to be exported. Export selection
The goal of this procedure is to show:
• The path to data upload menu
• Procedure for reccord file selection
• Physical file upload on USB drive
• MS Excel file import and file formating
Connect the USB drive to the Minisonoc II, Confirm transfert.
Wait
Export. pending
°°°°
When transfert completed, file tree appears as follow:
USB Drive
USB Drive
Ultraflux_Minisoncic_II_P_SN00017
File indicates the serial number of the instrument
(ex: SN00017)
Logger_Example 1
File indicate reccord name
(ex: Example 1)
Example 1_2017.11.22_23h38_config.txt
Text file including instrument settings during the reccord
Example 1_2017.11.22_23h38.ind001.log
Spreadsheet file including data reccord
(....)
(....)
