Compressor Unit Instruction Manual
2. INSPECTION
2.1 Shipping List ........................................................................................... 2-1
2.2 Compressor Unit ..................................................................................... 2-2
2.3 Connecting Piping (Flexible Hoses) ....................................................... 2-2
2.4 Cables ..................................................................................................... 2-2
2.1 Shipping List
When a product(s) delivered, make sure that there is no damage or shortage of delivered
items by checking the external view of the package and the shipping list attached.
Please read the enclosed cover letter for the details. Depending on your specification, the
option part(s) in Table 2-2 is attached.
Table 2-1 Shipping List
Item Quantity
Compressor Unit 1
This Instruction Manual 1
REMOTE/RESPONSE Connector 1
FAILURE OUT Connector 1
RS232C Connector 1
Table 2-2 Optional parts
Item Quantity
Input Power Cable (3m or customized length) 1
Refrigerator power cable (15m or customized length) 8
Flexible Hose (15m or customized length) 2
Helium Manifold (with 4 branch pipes) 2
Lipped Bowl Spanner (Flexible hoses installing tool) 2
Gasket for Helium Coupling (Spare) 4
(*1)The quantity of a refrigerator power cable is decided with the number of
refrigerators. The required number is different depending on your specification.
(*2)
The volume of flexible hoses may change according to the specifications.
(*3)Two sets of standard Helium manifold of with four branch pipes are shipped. The
number of branch pipes and the number of the manifold change with your
specification.
ULVAC CRYOGENICS INCORPORATED 2-1
