Installation
①Hold the braid support straight and tighten the self-sealing coupling by hand.
by hand.
②Tighten the self-sealing coupling using two spanners until the fittings are
firmly sealed. When using torque wrench, the recommended torque value is
20N･m.
Figure 3-3 Connecting Flexible Hose
Braid Support
T lf-sealing coupling
with a spanner.
ighten se
Hold with a
s
anner.
