Ulvac C30PZ - Page 61

Compressor Unit Instruction Manual
ULVAC CRYOGENICS INCORPORATEDB-3  
(1) REMOTE INPUT

































Figure B-1 REMOTE Wiring Diagram

−
DC24V
＋
C30PZ side
2
4
6
5
7
9
8
26
28
27
29
31
30
32
34
33
24
48
49
COMPRESSOR ON
COLDHEADNO.1ON
COMPRESSOR OFF
COLDHEADNO.1OFF
1
3
COLDHEADNO.7ON
COLDHEADNO.7OFF
COLDHEADNO.8OFF

COLDHEADNO.6OFF
COLDHEADNO.5OFF
COLDHEADNO.4OFF
COLDHEADNO.3OFF
COLDHEADNO.2OFF
COLDHEADNO.8ON
COLDHEADNO.5ON
COLDHEADNO.4ON
COLDHEADNO.6ON
COLDHEADNO.3ON
COLDHEADNO.2ON
C30PZ side
