UNI-T UT33C User Manual

Measurement Operation(1)
A. DC Voltage Measurement (see figure 2)
Warning
To avoid harms to you or damages to the Meter from electric shock, please do
not attempt to measure voltages higher than 500V although readings may be
obtained.
The DC Voltage ranges are: 200mV, 2000mV, 20V,
200V and 500V. To measure DC voltage, connect
the Meter as follows:
1. Insert the red test lead into theVΩmAterminal
and the black test lead into the COM terminal.
2. Set the rotary switch to an appropriate
measurement position in V range.
3. Connect the test leads across with the object
being measured.
The measured value shows on the display.
(figure 2)
13
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33C Specifications

General

DC Current Range	200μA/2000μA/20mA/200mA/10A
Diode Test	Yes
Continuity Buzzer	Yes
Battery	9V (6F22)
Weight	156g
DC Voltage Range	200mV/20V/200V
AC Voltage Range	200V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display	1999
Capacitance Range	Not available
Frequency Range	Not available
