UNI-T UT33C User Manual

l When square wave output testing has been completed, disconnect the connection
between the testing leads and the circuit under test.
General Specifications(1)
l Maximum Voltage (including transient overvoltage) between any Terminals
and Grounding: 500V rms.
l Fused Protection for VΩmA Input Terminal: 315mA, 250V fast type, φ5x20 mm
l 10A Terminal: Un-fused.
l Range: Manual ranging
l Maximum Display: Display: 1999.
l Measurement Speed: Updates 2~3 times /second.
l Temperature:
Operating: 0
o
C~40
o
C (32
o
F~104
o
F).
Storage: -10
o
C~50
o
C (14
o
F~122
o
F).
l Relative Humidity: 75% @ 0
o
C - 30
o
C; 50% @ 31 - 40
o
C.
General Specifications
29
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33C Specifications

General

DC Current Range	200μA/2000μA/20mA/200mA/10A
Diode Test	Yes
Continuity Buzzer	Yes
Battery	9V (6F22)
Weight	156g
DC Voltage Range	200mV/20V/200V
AC Voltage Range	200V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display	1999
Capacitance Range	Not available
Frequency Range	Not available
