UNI-T UT33C User Manual

Note
l When battery testing has been completed, disconnect the connection between
the testing leads and the circuit under test.
Measurement Operation (16)
H. The Model UT33D: Square Wave Output
To avoid damages to the Meter, do not allow output terminals (red test lead)
to reach higher than 10V.
Warning
To measure square wave output proceed as follows:
1. Set the rotary switch to OUT.
2. The square wave signal outputs between VΩmA and COM Terminals.
Note
l The frequency is approx. 50Hz.
l The output scope higher than 3Vpp when it is loaded 1MΩ.
28
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33C Specifications

General

DC Current Range	200μA/2000μA/20mA/200mA/10A
Diode Test	Yes
Continuity Buzzer	Yes
Battery	9V (6F22)
Weight	156g
DC Voltage Range	200mV/20V/200V
AC Voltage Range	200V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display	1999
Capacitance Range	Not available
Frequency Range	Not available
