UNI-T UT33C User Manual

l When continuity testing has been completed, disconnect the connection between
the testing leads and the circuit under test.
Measurement Operation (13)
F. Model UT33C: Temperature Measurement (see figure 6)
To avoid harms to you or damages to the
Meter, please do not attempt to input
voltages higher than 60V in DC or 30V in AC.
Warning
The Temperature measurement range is -40
o
C
~1000
o
C
or -40
o
F
~1832
o
F
. To measure
temperature, connect the Meter as follows:
1. Insert the red temperature probe into the
VΩmA
terminal and the black temperature
probe into the COM temperature.
( figure 6)
25
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33C Specifications

General

DC Current Range	200μA/2000μA/20mA/200mA/10A
Diode Test	Yes
Continuity Buzzer	Yes
Battery	9V (6F22)
Weight	156g
DC Voltage Range	200mV/20V/200V
AC Voltage Range	200V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display	1999
Capacitance Range	Not available
Frequency Range	Not available
