UNI-T UT33C User Manual

Measurement Operation (5)
C. DC Current Measurement (see figure 3)
Never attempt an in-circuit current
measurement where the voltage between
terminals and ground is greater than 60V.
If the fuse burns out during measurement,
the Meter may be damaged or the operator
himself may be hurt. Use proper terminals,
function, and range for the measurement.
When the testing leads are connected to
the current terminals, do not parallel them
across any circuit.
Warning
( figure 3)
17
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33C Specifications

General

DC Current Range	200μA/2000μA/20mA/200mA/10A
Diode Test	Yes
Continuity Buzzer	Yes
Battery	9V (6F22)
Weight	156g
DC Voltage Range	200mV/20V/200V
AC Voltage Range	200V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display	1999
Capacitance Range	Not available
Frequency Range	Not available
