G. The Model UT33B: Battery Test
Accuracy Specifications(6)
Range Resolution Internal Resistance
12V
9V
1.5V
10mV
10mV
10mV
H. The Model UT33D: Square Wave Output
Range
Illustration
Approx. output 50Hz square wave signal. As a simple signal
source with 47kΩ resistance output.
OUT
Remark:
l No overload protection.
l Make sure voltage output of calibrated equipment level is less than 10V to avoid
damages to the meter.
240Ω
1.8kΩ
30Ω
36
Model UT33B/C/D: OPERATING MANUAL

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the UNI-T UT33C and is the answer not in the manual?

UNI-T UT33C Specifications

General IconGeneral
DC Current Range200μA/2000μA/20mA/200mA/10A
Diode TestYes
Continuity BuzzerYes
Battery9V (6F22)
Weight156g
DC Voltage Range200mV/20V/200V
AC Voltage Range200V
Resistance Range200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display1999
Capacitance RangeNot available
Frequency RangeNot available
