3. Remove the screw from case bottom, and separate the case bottom from the
case top.
4. Remove the fuse by gently prying one end loose, and then take out the fuse
from its bracket.
5. Install ONLY replacement fuses with the identical type and specification as
follows and make sure the fuse is fixed firmly in the bracket. 315mA, 250V, fast
type, φ 5x20mm.
6. Rejoin the case bottom and case top, and reinstall the screw.
Replacement of the fuses is seldom required. Burning of a fuse always results from
improper operation.
** END **
Maintenance(4)
40
Model UT33B/C/D: OPERATING MANUAL

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the UNI-T UT33C and is the answer not in the manual?

UNI-T UT33C Specifications

General IconGeneral
DC Current Range200μA/2000μA/20mA/200mA/10A
Diode TestYes
Continuity BuzzerYes
Battery9V (6F22)
Weight156g
DC Voltage Range200mV/20V/200V
AC Voltage Range200V
Resistance Range200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Display1999
Capacitance RangeNot available
Frequency RangeNot available
