UNI-T UTD4000 Series User Manual

Technical Indicators
107
Sampling
Sampling modes
Equivalent
Real-time
Acquisition rates
CH1, CH2 : single channel 2GS/s, two channels 1GS/s
CH3, CH4 : single channel 2GS/s, two channels 1GS/s
Average
50GS/s(UTD4204C/UTD4304C)
When all channels have made N acquisitions simultaneously, N is selectable from
2, 4, 8, 16, 32, 64, 128 to 256.
Input
Input coupling
DC, AC, GND
Input impedance
1 2% M in parallel with
± ±
Ω 3pF
16
Probe attenuation
1X, 10X, 100X, 1000X
Maximum input voltage
400V (DC + AC Peak, 1 MΩ
)
input impedance
Time delay between channels (Typical)
150
ps
