UTD4000 Four-channel
User Manual
Horizonta
l
Waveform interpolation
sin (x) / x
Recording length
1024k
Storage depth
24k (Max)
Equivalent storage depth
dual time base
( )
60M
Scanning range (s/div)
1ns/div~50s/div (300MHz)
2ns/div~50s/div (200MHz, 150MHz)
5ns/div~50s/div (100MHz)
At 1-2-5 increment
Accuracy of sampling rate and delay
time
±
50ppm (any time interval ≥1ms)
Time interval ( T)
Measurement accuracy (full bandwidth)
△
Single : sampling time interval ppm x reading ns
average values sampling time interval ppm x
reading ns
± + +
> : ± +
+ .
(1 50 0 6 )
16 (1 50
0 4 )
.
