UNI-T UTD4000 Series

2. Accessing signals
Your UTD4000 Four-channel digital storage
oscilloscope has four input channels and an external
trigger input channel, as shown in Figure 1-6. Please
access signals in the following steps :
Connect the probe of the digital storage
oscilloscope to the CH input terminal and set
the attenuation switch of the probe to X
Figure
①
,
( - ).
1
10
1 7
Figure 1-6
Four-channel input and external
trigger channel
8
EXT external trigger channel
–
Figure 1-7 Setting the attenuation switch of
the oscilloscope probe
UTD4000 Four-channel
User Manual
