Table 2-5b Explanatory notes for the digital filtering menu (2)
Function Menu
Setup
Explanatory Note
Upper Limit
----
Effective only during low-pass filtering or band-pass filtering.
Use the control knob to set the maximum
frequency
MULTIPURPOSE
Lower Limit
----
Effective only during high-pass filtering or band-pass filtering.
Use the control knob to set the minimum
frequency
MULTIPURPOSE
Y Offset
----
Use the control knob to move the waveform
vertically
MULTIPURPOSE
Pre
1 /2
----
Return to previous page
Y Level
----
Use the control knob to adjust the vertical
graticule factor
MULTIPURPOSE
