Table 2-16 Slew rate setup
Trigger occurs when the signal slew rate within the threshold is
greater than the set slew rate
Trigger occurs when the signal slew rate within the threshold is
smaller than the set slew rate
Trigger occurs when the signal slew rate within the threshold
equals to the set slew rate
Select the rising edge within the threshold for trigger
Select the falling edge within the threshold for trigger
Set the slew rate value with the control knob
Change the low level value with the control knob
Change the high level value with the control knob
Change the high and low level value with the
Return to the slew rate trigger menu
When alternate trigger is selected, the trigger signal will be present in two vertical channels. This triggering
mode is suitable for observing two signals of unrelated signal frequencies Alternate trigger can also be
used to compare pulse widths
