Unico 1105 User Manual

Product Overview 2-9
2.4 Specifications
Detailed drive specifications are provided in Table 2-2 through Table 2-14 below.
Table 2-2—Electrical Specifications
Input Supply
Line voltage:
200 to 240 V AC, three phase (1100, 1105, 1120, 1130,
and 1200)
220 to 240 V AC, single-phase (1110)
380 to 480 V AC, three-phase (1100, 1105, 1120, 1130,
1200, and 1230)
440 to 480 V AC, single-phase (1110)
500 to 600 V AC, three-phase (1100, 1105, and 1130)
Phase-sequence insensitive
Overvoltage Category III (IEC 664-1)
Voltage tolerance:
–10% of minimum, +10% of maximum
Imbalance:
Maximum ±3% of nominal input voltage
Frequency:
47 to 65 Hz
Short circuit rating:
85,000 Arms symmetrical
Power factor:
Displacement:
1.00 at all loads and speeds
Overall:
0.99 at rated load (1230)
0.94 at rated load (1100, 1105, 1130, and 1200)
0.65 at rated load (1110)
Harmonic distortion:
(1230) Harmonics are below the limits defined in IEEE-519
for all I
SC
/I
L
. Each individual harmonic current fulfils IEE-519
table 10-3 for I
SC
/I
L
≥ 20. Current total harmonic distortion
(THD) and each individual current harmonic fulfil IEC 61000-
3-4 table 5.2 for R
SCE
≥ 66. The values will be met if the
supply network voltage is not distorted by other loads.
R
SC
THD Voltage
(%)
THD Current
(%)
20
4
4
100
0.8
5
Output Rating
Voltage:
Zero to input supply voltage, three-phase (1100, 1105, 1120,
1130, 1200, and 1230)
Zero to 90% of input supply voltage, three-phase (1110)
Frequency:
Zero to 120 Hz for transducerless vector control
Zero to 180 Hz for transducer-based vector control
Zero to 300 Hz for variable-frequency control
Switching frequency:
16 MHz control:
1.0, 1.9, 3.9, 7.8, and 15.6 kHz (see Table 2-14)
20 MHz control:
Programmable from 1.1 to 6.5 kHz (see Table 2-14)
40 MHz, 100 MHz, 270 MHz, Compact 100 MHz, and
Compact 150 MHz controls:
Programmable from 1.0 to 12.0 kHz (see Table 2-14)
