Unico 1105 User Manual

Mechanical Installation 3-21
Table 3-13—1200 Power Dissipation (continued)
Power
Dissipation
CT
VT
ET
Control
Heat Sink
Total
hp (kW)
hp (kW)
hp (kW)
kW
kW
kW
460 V
200
250
300
0.275
3.599
3.874
(150)
(185)
(225)
250
300
400
0.325
4.437
4.762
(185)
(225)
(300)
300
400
500
0.375
5.274
5.649
(225)
(300)
(375)
400
500
600
0.475
6.949
7.424
(300)
(375)
(450)
500
600
800
0.575
8.624
9.199
(375)
(450)
(600)
600
800
1000
0.675
10.298
10.973
(450)
(600)
(750)
Table 3-14—1230 Power Dissipation
Power
Dissipation
CT
VT
ET
Control
Heat Sink
Total
hp (kW)
hp (kW)
hp (kW)
kW
kW
kW
460 V
11/2
2
—
0.074
0.080
0.154
(1.1)
(1.5)
2
3
—
0.074
0.092
0.166
(1.5)
(2.2)
3
5
—
0.076
0.130
0.206
(2.2)
(3.7)
5
71/2
—
0.080
0.208
0.288
(3.7)
(5.5)
71/2
10
—
0.100
0.302
0.400
(5.5)
(7.5)
10
15
20
0.104
0.386
0.490
(7.5)
(11)
(15)
15
20
25
0.116
0.578
0.694
(11)
(15)
(18)
20
25
30
0.124
0.746
0.870
(15)
(18)
(22)
25
30
40
0.134
0.938
1.072
(18)
(22)
(30)
30
40
50
0.164
1.106
1.270
(22)
(30)
(37)
40
50
60
0.186
1.440
1.626
(30)
(37)
(45)
50
60
75
0.206
1.802
2.008
(37)
(45)
(55)
60
75
100
0.242
2.136
2.378
(45)
(55)
(75)
75
100
125
0.278
2.664
2.942
(55)
(75)
(90)
100
125
150
0.328
3.450
3.778
(75)
(90)
(110)
(continued)
