User manual for NERO / NERO INSTANT
Page 8Version 3.2 / December 2017
ТМ
3.4 Installation of the vending machine
Figure 1 - Machine in the package
The vending machine’s inner components are all wrapped in packing.
Before turning the machine ON please make sure that all of the packing
materials have been removed.
For NERO: Before putting to use please remove the transportation
bracket, which holds the coffee grinder unit, by loosening the not, shown
in gure 2.
The ROSSO and ROSSO INSTANT vending machines cannot be
installed in open air. The vending machines should be installed in dry
premises with temperatures ranging from 10
0
to 30
0
C.
The vending machine can be installed on a table or any other suitable
stand (it is recommended to use NERO or NERO with payment systems
stand to install the machine). If needed please level the vending ma-
chine with the help of the adjustable pegs.
The vending machine should be installed at a distance of 5cm from
the wall to provide for sufcient ventilation.
It is prohibited to cover the vending machine with fabric or any other
such material.
The vending machine must not have a vertical tilt of more than 2
0
.
Remove machine packing, take the master-key, program the ma-
chine’s lock with it, then open the door with the functional key (the key is
xed with a plastic band to the cover of the machine by the cup retainer)
– (see section 3.5.15).
ATTENTION: If the transportation bracket would not be removed before the start of opera-
tions, this can cause excessive vibration in machine parts, which can cause premature break-
downs and failures.
Figure 2 - Removal of the transportation bracket
After removing the transportation bracket, install the bafe plate in
the NERO vending machine (se gure 4 position 1), which comes with
the package.
To install the bafe plate, hang it on the bolt (see gure 3 position 1),
which is situated on the left inside wall of the vending machine’s body
under the espresso group.
1
Figure 3 - Installation of bafe plate
