Unicum NERO - 3 Purpose; Technical Features

User manual for NERO / NERO INSTANT
Page 6Version 3.2 / December 2017
ТМ
3.0 PURPOSE
The NERO and NERO INSTANT drinks vending machines are designed for the preparation and sales of:
• Hot drinks using coffee beans (Model NERO);
• Hot drinks using instant coffee (Model NERO INSTANT);
• Hot drinks made of instant ingredients;
• Hot water.
The ingredients that you use for making the drinks, must be declared by the ingredient manufacturer as
t for use in open containers.
3.1 Technical features
Parameters NERO NERO INSTANT
Height (А), maximum 800 mm 800 mm
Width (В), maximum 385 mm 385 mm
Depth (С), maximum 495 mm 495 mm
Weight, maximum 55 kg 55 kg
Voltage 220 - 230 V 220 - 230
Power frequency 50 Hz 50 Hz
Power consumption (max) 1800 W 1800 W
Consumption of electricity per day,
when surrounding air temperature
is 22
0
C and making 40 drinks (each
100ml), maximum permissible (*)
3 kWh 3 kWh
External water supply
Water pressure, minimum 0.5 bar (0.05 MPa) 0.5 bar (0.05 MPa)
Water pressure, maximum 8.5 bar (0.85 MPa) 8.5 bar (0.85 MPa)
Connection to water supply line G 3/4
’’
G 3/4
’’
Internal water supply
Hardness 0.9 - 1.0 mgeq/l 0.9 - 1.0 mgeq/l
Calcium 18 - 20 mg/l 18 - 20 mg/l
Number of containers
Coffee bean container 1 pcs -
Instant ingredients container 3 pcs 4 pcs
Volume of containers (
**
)
Coffee beans 1,0 kg -
Instant coffee - 0,7 kg
Powdered milk
/ Granulated milk 1,5 / 0,75 kg 2,2 / 1,1 kg
Chocolate 1,5 kg 2,4 kg
Vanilla 1,0 kg 2,4 kg
*) The estimated power consumption indicators are average numbers and are shown only as reference points;
**) The quantity of ingredients can be different from the one shown depending on the specic weight of the ingredient.
