Installation and Configuration
9) Browse to the folder where the port driver is saved.
Figure 21: Saving port driver
10) Click “Next”. The installation of the port driver begins. If a message opens, saying the soft-
ware has not passed Windows Logo testing, click “Continue Anyway”.
11) Click “Finish”. A dialogue box will open and inform you that new hardware is installed.
Install the Port Driver on Windows 7
When switching between mass storage mode and network mode, it takes about 30 sec-
onds before the module can be accessed with the 192.5.36.229 address.
1) Connect a mini-USB type B cable between the USB port on your PC and the management
port on the module.
2) Press the Mode button twice to change the mode to mass storage.
The module will now turn up as a mass storage device on your computer. This is indicated
by slow flashing blue light on the Mode button LED.
A31003-M2000-J109-01-7631, 30/06/2020
Wireless Service Gateway WSG, Installation Guide 25
