Assembling and Installing the Phone
2.2.4 How to Connect the Phone
1. Plug the LAN cable into the connector at the bottom of the telephone and connect the
cable to the LAN resp. switch. If PoE (Power over Ethernet) is to be used, the PSE (Power
Sourcing Equipment) must meet the IEEE 802.3af specification.
For details about the required power supply, see the following table:
2. If Power over Ethernet (PoE) is NOT supported or an OpenScape Desk Phone CP600
phone has more than one Key Module connected:
Plug the power supply unit into the mains. Connect the plug-in power supply unit to the
jack at the bottom of the phone.
3. If applicable, connect the following optional jacks:
• LAN connection to PC
• Headset (accessory)
Model Power Consumption
OpenScape Desk Phone CP200/CP205 PoE (Power Class 1)
OpenScape Desk Phone CP400 PoE (Power Class 2)
OpenScape Desk Phone CP600
1
1 If more than one Key Module is connected, a Plug-in Power Supply is required (see below).
PoE (Power Class 2)
Plug-in Power Supply Order No.
Power Supply, power cable and plug (Type E+F) for EU L30250-F600-C141
Power Supply, power cable and plug for Great Britain L30250-F600-C142
Power Supply, power cable and plug for USA L30250-F600-C143
Power Supply, power cable and plug for Switzerland L30250-F600-C182
Power Supply, power cable and plug for Italy L30250-F600-C183
Power Supply, power cable and plug for Australia L30250-F600-C184
Power Supply, power cable and plug for South Africa L30250-F600-C185
Power Supply without power cable L30250-F600-C148
