inbetriebnahme.fm

A31003-C1000-M102-5-76A9, 09/2017

OpenScape Desk Phone CP200/CP205/CP400/CP600 HFA, Administration Manual

Startup

Quick Start

Setup using a DHCP server on Unix/Linux

The following snippet from a DHCP configuration file (usually dhcpd.conf) shows how to set up

a configuration using a vendor class and the "vendor-encapsulated-options" option.

class "OptiIpPhone" {

option vendor-encapsulated-options

# The vendor encapsulated options consist of hexadecimal values for

the option number (for instance, 01), the length of the value (for in-

stance, 07), and the value (for instance, 53:69:65:6D:65:6E:73). The

options can be written in separate lines; the last option must be fol-

lowed by a ’;’ instead of a ’:’.

# Tag/Option #1: Vendor "Siemens"

#1 7 S i e m e n s

01:07:53:69:65:6D:65:6E:73:

# Tag/Option #2: VLAN ID

#2 4 00 1 0

02:04:00:00:00:0A;

match if substring (option vendor-class-identifier, 0, 11) =

"OptiIpPhone";

}

2.3.8.2 Using Option #43 "Vendor Specific"

Alternatively, option #43 can be used for setting up the VLAN ID. Two tags are required:

• Tag 001: Vendor name

• Tag 002: VLAN ID

The Vendor name tag is coded as follows (the first line indicates the ASCII values, the second

line contains the hexadecimal values):

The following example shows a VLAN ID with the decimal value "10":

For manual configuration of the VLAN ID see Section 3.2.2.1, “Automatic VLAN discovery using

LLDP-MED”.

Code Length Vendor name

17Siemens

01 07 53 69 65 6D 65 6E 73

Code Length VLAN ID

240010

02 04 00 00 00 0A
