Administration
A31003-C1000-M102-5-76A9, 09/2017
70 OpenScape Desk Phone CP200/CP205/CP400/CP600 HFA, Administration Manual
administration.fm
System Settings
3.5.3 HFA Emergency Gateway Settings
For enabling survivability, the phone switches to a backup communications system in case the
main system fails.
The settings are analog to those for the main system (see Section 3.5.2, “HFA Gateway Set-
tings”).
Administration via WBM
System > Standby gateway
Network > Port configuration
Standby Gateway
System type
IP address
Gateway ID
Subscriber number
Submit
Reset
Password
System H.225
Standby H.225
System Cornet TLS
Standby Cornet TLS
System H.225 TLS
Standby H.225 TLS
1300
Port configuration
1720
4061
RTP base
5004
1300
1720
4061
Gateway
Standby gateway
4060
4060
LAN port speed
Automatic
Submit
Reset
Automatic
PC port speed
PC port autoMDIX
disabled
PC port mode
LDAP server
HTTP proxy
389
0
