UpadIII product manual
www.unilumin.cn 5
2. Installation and Wiring
2.1 Package Check-out
First check whether the package is damaged, if the package is normal, then continue to
check the main components according to the shipping list. If there are any discrepancies, please
do not hesitate to contact us.
Main parts: cabinet unit, signal cable, power cable, USB cable, DVI cable, sending card,
control PC and accessory components, specific parts and their quantities can be found in the
shipping list.
2.2 General Installation
2.2.1 Floor Installation
1） Check the bottom of the structure whether vertical, keep the levelness between ±1mm;
2） Connect the ground beam and the back frame with plate;
3） Then install them from down to up, middle to sides, use the locks to connect the cabinets
from left to right, from down to up.(no limit on the horizontal quantity , less than 12 cabinets
on the vertical);
4） Fixed the cabinets against to the back frame with plate;
5） According to the actual situation of the installation site, sometime the sandbags and other
balance weight need to be pressed on the ground beam support.
