Universal Robots UR10e

If a blend radius is set, the robot arm trajectory blends around the waypoint, allowing the
robot arm not to stop at the point.
Blends cannot overlap, so it is not possible to set a blend radius that overlaps with the
blend radius of a previous or following waypoint.
If there is overlap of two blends, there will be a warning logged in the Log tab. See the
Log tab for more information.
WP_1
WP_2
WP_3
WP_4
*
32.3: Blend radius overlap not allowed (*).
