Radial 8 & 88 Operation Reference Manual 49379902 Rev. G
This Document Supports IM-UPS 5.0 and Higher
TOP VIEW
Left Amplifier Panel Assembly
(X Axis, Y Axis, Component
Transfer Axis)
Right Amplifier Panel Assembly
(Insert Axis, Theta Axis)
Interlock Control
Assembly
16 Channel
I/O Assembly
REAR VIEW
Servo Chassis
Assembly
AC Chassis
Assembly
Service
Disconnect
Pneumatic
Lockout
Assembly
